Combo Rescue
VERSATILE, DURABLE.
The E-ONE combo rescue provides a blend of capabilities of both walk-in and non-walk-in rescue bodies. The rear body, with all of the spacious storage features of the non-walk-in body, joins a forward walk-in module for mission-critical duties. Command, rehab, hazmat, or dive/swift water rescue are just a few of the duties the forward module can accommodate on scene to elevate your response capabilities.
Specifications
CHASSIS
- E-ONE, Spartan, Navistar and Freightliner
CAB STYLE
- E-ONE Typhoon and Cyclone: 2-door short or 4-door short/medium/long/stretched long/extended
- Spartan FC-94: MFD
- Spartan Metro Star and Gladiator: 2-door LTD and 4-door SMFD/MFD/EMFD/LFD/ELFD
- Navistar and Freightliner: 2-door and 4-door
FRONT BUMPER
- E-ONE chassis: 10″ high stainless, 10″ or 12″ heavy-duty channel; 4″ to 30″ extensions
- Spartan FC-94: 12″ high stainless steel; non-extended or extended 24″
- Spartan Metro Star and Gladiator: 12″ high stainless, 12″ high-heavy duty channel; 6″ to 28″ extensions
BODY
- Aluminum: Heavy wall mainframe extrusions, 1/8″ and 3/16″ wall exterior body and roof extrusions, 1/8″ plate for compartments
- OR
- Stainless steel: 304L material, 12-gauge body platework and 7-gauge for body subframe, double-flex mounting system, painted FRP overlays with roll-up doors
DOORS
- Hinged or roll-up with satin or painted finish
CREW ENTRY
- Side entry door standard; walk-through from cab also available with Typhoon and Cyclone cabs
CREW SEATING
- Bench seat-style seating available inside crew area in body
INTERIOR STORAGE
- Storage compartments available in upper interior of body crew area with roll-up doors or cargo netting
BREATHING AIR SYSTEM
- Cascade breathing air system with fill station available; onboard compressor also available
ELECTRICAL SYSTEM
- Multiplex electrical system with color display for driver or driver and officer, LED warning / scene lighting; light tower on cab or body available
GENERATOR
- Hydraulic or PTO generator available
REELS
- Cord reel options available for 120/240V, tool air and hydraulic tools
Features and Benefits
Extruded Aluminum Body
Combo Rescue bodies are constructed with aluminum extrusions and feature a Walk-In module with a side entry door ahead of a Non-Walk-In rescue body providing additional enclosed storage space without giving up the benefits of a Walk-In Rescue.
Stainless Steel Body Features
The stainless steel body design uses brake-formed 304L stainless-steel for corrosion resistance. The double-flex body-mounting system cushions the body from harsh road conditions. When equipped with roll-up doors, all painted surfaces use FRP panels that will not corrode.
Cab to Body Walk-Through
Typhoon and Cyclone cabs are available with a walk-through option to enter the interior of the forward body module from the cab.
Rescue Body Interior
The walk-in interior space can be customized to accommodate a wide array of duties such as communications, rehab, and hazmat to support your crew in the field.
Breathing Air System
Combo rescues are available with cascade breathing air systems, SCBA quick-fill stations and storage racks to hold spare SCBA cylinders.
Command Cab
The Typhoon and Cyclone cabs are available in a 3-door design with a desk and cabinets to create a separate work or command area for big incidents.
Storage Options
To effectively utilize all the storage space in the body, a wide range of shelves, roll-out trays, fixed partitions and pull-out tool boards is available to store equipment.
